Runtime Resource Overlay (RRO) Explained With Real AOSP Examples

Photo by The Average Tech Guy on Unsplash

If you’ve worked on AOSP customization long enough, you’ve probably heard something like:

“Don’t modify framework resources directly. Use an overlay.”

At first, that sounds simple.

Then real-world questions start appearing:

• What exactly is RRO?
• Why use RRO instead of modifying source code?
• What is the difference between static and dynamic overlays?
• Where do overlays live in AOSP?
• How does Android know which resource to replace?
• When should we use RRO and when should we modify Java business logic instead?

For many Android and Automotive developers, RRO becomes one of the first customization mechanisms they interact with.

This article walks through Runtime Resource Overlay (RRO) using real AOSP examples and explains where it fits in production customization workflows.

In this article we will cover:

• What RRO is
• Why Android introduced overlays
• Static vs Dynamic overlays
• AOSP folder structure
• Create an overlay package
• Real implementation example
• Enable and disable overlays
• Production use cases
• Common debugging commands

Why Android Needed RRO

Suppose a customer asks:

Change navigation bar color Replace launcher icon Update status bar dimensions Customize AAOS top bar layout

One option:

Modify framework code directly.

Example:

frameworks/base/core/res/

But direct changes create problems:

• difficult upgrades
• merge conflicts
• repeated maintenance
• customer-specific branches

Android introduced overlays:

Base Resource
        +
Overlay Resource
        ↓
Final Resource

Instead of changing original files, Android replaces resources at runtime.

What Exactly Is RRO?

RRO stands for:

Runtime Resource Overlay

RRO allows one package to replace resources of another package without modifying source code.

Examples:

Replace:

<string name="car_name">
Android Automotive
</string>

With:

<string name="car_name">
My Custom Vehicle
</string>

without touching original implementation.

High-Level Architecture

Target Package
        ↓
Framework Resources
        +
Overlay Package
        ↓
OverlayManagerService
        ↓
Modified Resources

Android decides which resources to override.

Static vs Dynamic Overlay

Static Overlay

Enabled automatically during boot.

Configured:

android:isStatic="true"

Examples:

• OEM customization
• product branding
• production UI changes

Dynamic Overlay

Enabled during runtime.

Commands:

adb shell cmd overlay enable

Examples:

• themes
• runtime customization
• feature switching

Real AOSP Folder Structure

Example:

device/company/product/overlay/

     AndroidManifest.xml

     res/

        values/

            config.xml

Another example:

vendor/company/overlay/

Automotive projects commonly use:

device/
product/
vendor/
overlay/

AndroidManifest Configuration

Example:

<manifest>

<overlay

android:targetPackage=
"com.android.systemui"

android:isStatic="true"

android:priority="10"/>

</manifest>

Important fields:

| Field         | Purpose            |
| ------------- | ------------------ |
| targetPackage | package to modify  |
| isStatic      | boot enabled       |
| priority      | overlay precedence |

Android.bp Example

runtime_resource_overlay {

name:"SystemUIOverlay",

product_specific:true,

theme:"SystemUIOverlay"

}

This builds overlay package.

Real Example: Modify Status Bar Height

Suppose original resource:

Location:

frameworks/base/packages/SystemUI/res/
values/dimens.xml

Original:

<dimen name="status_bar_height">

24dp

</dimen>

Overlay:

res/values/dimens.xml

Add:

<resources>

<dimen name="status_bar_height">

32dp

</dimen>

</resources>

No framework modification needed.

Real AAOS Example

Suppose customer requests:

• change top bar icon
• modify bottom bar layout
• replace dimensions
• customize spacing

Overlay:

packages/apps/Car/SystemUI

Replace:

car_top_system_bar.xml

or:

dimens.xml

without touching framework code.

Enable Overlay

List overlays:

adb shell cmd overlay list

Enable:

adb shell cmd overlay enable \
package_name

Disable:

adb shell cmd overlay disable \
package_name

Verify Active Overlay

adb shell dumpsys overlay

Check:

enabled
priority
target package

Common Production Mistake

Developers often try:

RRO everything

But overlays cannot modify:

• Java business logic
• Binder implementation
• service behavior
• controller flow

Example:

CarSystemBarController.java

If logic changes:

if(vehicleState)

RRO cannot help.

Source modification becomes necessary.

RRO vs Source Changes

Use RRO:

✅ colors ✅ dimensions ✅ strings ✅ layouts ✅ icons

Modify source:

✅ Java logic ✅ service behavior ✅ controller flow ✅ framework implementation

Useful Commands

List:

adb shell cmd overlay list

Enable:

adb shell cmd overlay enable package

Disable:

adb shell cmd overlay disable package

Dump:

adb shell dumpsys overlay

Common Interview Questions

What is RRO?

Runtime Resource Overlay.

Can RRO modify Java code?

No.

Resources only.

Difference between static and dynamic?

Static:

boot enabled

Dynamic:

runtime enabled

Which service manages overlays?

OverlayManagerService

Final Thoughts

RRO is one of the most widely used Android customization mechanisms.

It enables customization without touching framework resources directly and helps reduce maintenance overhead.

But understanding where RRO stops is equally important.

Resources
      ↓
RRO

Business Logic
      ↓
Source modification
